- X=51.2", Y=51.2", Z=3" (1,300 X 1,300MM)
The FC Accu-CUT™ enclosed fiber laser cutter is designed and engineered – with its 3-Axis ball screw transmission for precision and accuracy. Now includes a 4’x4′ pull-out platform for easier material handling. Power options from 700W up to 2KW of IPG laser cutting power allow you to process stainless, carbon steel, aluminum, brass, copper, titanium, and other metal alloys. Save up to $5,000 by talking to a sales rep!
Josh is the technician that saved our busy season! Our experience with our technology maintenance visit was amazing. Josh walked us through everything we didn't know that we didn't know about our equipment and helped us by getting our lasers back into tip-top shape.
The ACCU-Cut goes the extra mile with a precision ball screw with support from dual HiWinn rail guides for the X, Y, and Z axis’. The dual Y-axis is ball screw driven on both sides then further supported by 20mm HiWinn Dual Rails and bearings. All of which are critical for maintaining max precision kerf cutting especially during high speed processing.
Accu-CUTTM is equipped with premium components geared for Extreme Precision and position accuracy (±0.008mm). All 3 axes are ball screw driven with dual HIWINN rails and bearing blocks for maximum precision cutting.
Y axis dual drive
X single drive
Yaskawa’s SGM7J servo was designed to maximize responsiveness in applications where precise load matching is of critical importance. This family of medium inertia rotary, brushless servo motors was created with low capacity applications in mind, yet can respond with rated speeds to 3000 rpm and torque ratings up to 2.39 N-m (21 in-lb) when an application requires it. 24-bit encoder resolution maintains industry-leading positional accuracy in any operating condition.
Manufactured to aerospace standards to 6061 T6 – hardened aluminum alloy. T6 temper 6061 aluminum is treated to provide the maximum precipitation hardening (therefore yielding maxium strength). Aviation aluminum has many advantages beyond strength including light weight, corrosion resistant, low density, all of which contribute ot improved processing speeds.
Premium fiber laser head suitable for medium and higher power fiber lasers in industrial applications. Includes a new dust-proof design that eliminates collimation lens contamination. Also, a top protective window was added to the collimation assembly as well as the bottom protective window structure is also fully upgraded with protection. This double protection design enhances the user experience by practically eliminating any lens contamination risk.
• Optimized optical configuration offers a smooth and efficient airflow design
• Improved anti-collision function prevents damaging the laser head
• Turntable focus adjustment with range of 20mm, accuracy – 0.05mm
• Collimation lens, focusing lens, and nozzle equipped with cooling structures
Machine mounted and adjustable Monitor connected to Windows 10 PC. Includes CYP-CUT laser interface pre-installed.
Designed for laser cutting CypCUT is a popular and robust software for industrial fiber laser systems. It includes control card, breakout board with a wireless remote along with a free standing capacitive height adjustor. On the VIDEOS tab you can view the nesting utility.
NOTE: All FC series laser purchases include a minimum of 2 days install and training of which operators will be able to understand CypCUT functionality.
As we continue to design, engineer, and assemble our laser systems here at Boss we have expanded our facilities to 43,000 sq. ft. We continue to build in-house as well. We strive to improve our quality output by upholding our IS0-9001:2015 certifcation. We are also members of BBB, D&B, System for Award Management (SAM), and Laser Institute of America (LIA). See a laser Live! Come and visit us in Sanford, FL just 20 min North of Orlando.
Get producing quickly and efficiently! Boss’ fiber laser cutters include Two (2) Days of On-Site Installation & Training that covers machine safety, set-up, basic software functions, and if time permits new job set up.
Our dual temperature water chiller provides 4200 watts of cooling capacity. Designed for cooling 1000W fiber lasers they are include both a dual circulating refrigeration and dual temperature control systems.
Removable SawTooth Blade Cutting Platform and material clamps for sheet metal processing.
ISO 9001 is the International Standard for a quality management system (“QMS”). In order for our company to be third party certified to the ISO 9001 standard, we had to follow the requirements set forth within the Standard. ISO 9001 evaluates whether our QMS is first appropriate and effective, and then forces us to identify and implement improvements.
In short the standard demonstrates our ability to consistently provide products and services that meet customer and regulatory requirements and to demonstrate continuous improvement. The current version is ISO 9001:2015, which was published in September of 2015 (thus the: 2015).
Our In-House Tech Support team is here to serve and support from the day you receive your BOSS Laser and for as long as you own the machine. Our tech support utilizes video, help manuals, phone, email, remote support via. Team Viewer, FaceTime, and even on-site support if necessary. Need on-site installation and training for your team? Give us a call we’re here to help!
Having supported thousands of businesses, hobbyists, educational, military, and Government institutions we know and understand how critical it is to be able to deliver competant and timely support. Quality support begins with warehousing ALL parts to the machine you purchase – in our facilites. That way if you have an issue with your laser cutter we can not only diagnose the problem we can also ship you the part you need same or next day. This way you experience minimal down time.
Boss’ fiber laser power warranty is two (2) years covers all parts including the fiber laser source. Have questions? We’re here to help: 407-988-2420.
Any feelings of skepticism you might have about investing in a new laser machine is completely normal! This is why BOSS LASER makes every effort to absorb as much risk as possible so you’re free to make a good decision. We want to make it easy for you to prove that our laser systems are quality machines backed by quality support.
We want you as our customer to be 100% satisfied. BOSS LASER guarantees you a 30-Day Return window (beginning the date of receipt) to evaluate your purchase. Click here for details.
BOSS LASER warrants its products and parts against defects in materials or workmanship for two (2) years from the original date of receipt. Click here for details.
