LS-1420 Co2 Laser Cutter and Engraver

April Sale Banner

Hybrid Servo Drive – Fastest in Class – 4X speed compared to stepper motors make the LS Series the Best CO2 Laser Cutters and Engravers for Small Businesses that have outgrown their desktop “hobby” lasers. The Boss LS-1420 is the perfect alternative to Glowforge when speed, power, and production capabilities define actual value. Raster engraves up to 1,500 mm/sec or 59″ per/sec; faster job times mean increased productivity. Upgrade to 70 watts to cut up to 3/8” wood and acrylic. 4-Way pass-throughs for more excellent material handling capability.

TO SCHEDULE A FREE VIRTUAL DEMO CLICK HERE

From: $4,997.00

Build your machine

Features

4-Way Material Tru-Pass-Thru™ Points For Greater Flexibility

Dramatically improve material flexibility using Boss’ Tru-Pass-Thru™ points. Expand your production work area with Boss’ 4 way material pass through points. Slide and extend your material outside of the work area either front to back or side to side.

50-70W CO2 Laser Cutting Power

Boss’ X-Series™ – Select between 50 and 70 watts of cutting power with a life time performance of up to 12,000 hours.
We test our laser multiple times throughout the assembly process to ensure a quality beam profile and maximum power.

The X-Series is engineered to handle demanding production environments and long workdays while delivering consistent results for every job.
By constantly refining and improving the beams power density the X-Series generates a powerful cutting beam with exceptional engraving resolution.
Each X-Series tube comes with a (1) year warranty.”

Laser Software

RD Works – Basic Operations Software.

LightBurn™ Software – Recommended “Optional” layout, editing, and control software package that is extremely intuitive and feature rich.
LightBurn is a native application written for Windows, Mac OS, and even Linux operating systems. Comes Camera compatible.

Designed & Engineered In USA By Boss Laser

As we continue to design, engineer, and assemble our laser systems here at Boss we have expanded our facilities to 43,000 sq. ft. We continue to build in-house as well. We strive to improve our quality output by upholding our IS0-9001:2015 certifcation. We are also members of BBB, D&B, System for Award Management (SAM), and Laser Institute of America (LIA). See a laser Live! Come and visit us in Sanford, FL just 20 min North of Orlando.

Honey Comb & Knife Blade Platforms Offers Flexible Material

Both the Knife Blade and Honeycomb platforms are included for flexibility whether cutting or engraving material.

Illuminated LCD Panel For Quick Touch Laser Head Control

Durable, machine mounted illuminated LCD touch pad for operators to easily gain dependable laser head, power, and job control.

Inline Beam Combiner Illuminates Red Dot For Improved Accuracy And Alignment

The infrared laser beam is invisible to the naked eye but, the included Inline Beam Combiner accurately illuminates a red dot over your material taking the guess work out of where the laser will start to process.

USA Focal Lenses

Made-In-USA Optics – NEW! Meniscus focal lenses enable high quality engraving and deeper cutting for your laser engraving or cutting application. Unlike cheaper plano-convex lenses with a flat side our meniscus focal lenses yield a smaller focused spot with a 14% improved beam transmission to the material.

Push Button Z-Axis

Motorized Z-Table With Working Height Of 7.5″ accommodates taller objects.
The taller cabinet for our Entry-Level LS-1416 laser cutter gives you Industrial level work space including up to 7.5″ of vertical z-axis movement.
At the push of a button you can lower the platform to accommodate taller objects of up to 10″ in height.

WORK AREA FLEXIBILITY

4-Way Material Pass Thru Points - EXPANDS WORK AREA

X-SERIES™ Laser Power

Select Up to 70 Watts - Cut up to 3/8" material. Includes full 1-Year Warranty

PROTECT YOUR LASER

Analog mA meter & Digital water temp gauge for easy monitoring.

JOB CONTROL & SAFETY

- Illuminated LCD Panel for Push Button laser head control.
- Safety E-Stop button & Keyed Start Up
- 256 MB Flash Drive Job storage

CONNECTIVITY

Flexible laser to PC connection options: WiFi Ready, USB or Ethernet

SMART HINGE ACCESS PANELS

Safety lock panels for easy internal access

MOBILE STAND

Optional matching Steel stand with locking casters for easy mobility.

Hybrid Drive System

NEW! Hybrid Servo Drive™ – Fastest in Class – 4X speed compared to stepper motors. Raster engrave up to 1,500mm/sec. Faster job times for increased productivity.

Optional New & Easy Laser/PC Connectivity Via. WI-FI, Ethernet, Or USB

Various laser to PC connectivity choices – USB, Ethernet, or WiFI (router available for purchase).

New 256MB USB Flash Drive For Alternative Job Storage

As an alternative to the onboard memory available on the controller card you can also save or run jobs from the 256 MB USB flash drive.

New All-In-One™ Laser Head With Auto-Focus & Air-Assist

All-In-One laser head improves on the old side mounted probe with a new “All-In-One” built in Auto Focus function.  Now the head can automatically calibrate the distance between the material and laser for optimum focus.  Includes air-assist with air stream output for keeping the cutting or engraving area clean from debris and smoke.

PC Compatibility Windows, Mac OS, Or Linux

Using your current computer is no problem! Our native application software is written for Windows, Mac OS, and even Linux operating systems 32 or 64 bit.

Quality Management System (QMS) - ISO-9001 CERTIFIED

ISO 9001 is the International Standard for a quality management system (“QMS”).  In order for our company to be third party certified to the ISO 9001 standard, we had to follow the requirements set forth within the Standard. ISO 9001 evaluates whether our QMS is first appropriate and effective, and then forces us to identify and implement improvements.

In short the standard demonstrates our ability to consistently provide products and services that meet customer and regulatory requirements and to demonstrate continuous improvement.  The current version is ISO 9001:2015, which was published in September of 2015 (thus the: 2015).

Tech Support For Life Via. BOSS' In-House Laser Tech's And Engineers

Our In-House Tech Support team is here to serve and support from the day you receive your BOSS Laser and for as long as you own the machine.   Our tech support utilizes video, help manuals, phone, email, remote support via. Team Viewer, FaceTime, and even on-site support if necessary.   Need on-site installation and training for your team? Give us a call we’re here to help!

Warranty - 2 Year Limited Warranty

Boss has improved its warranty!  Our laser systems are warranted to be free from defects in material and/or workmanship under normal use and service for a period of two (2) years and one (1) year on the laser tube.

Warehoused Replacement Parts & Accessories For Quick Replacement

Having supported thousands of businesses, hobbyists, educational, military, and Government institutions we know and understand how critical it is to be able to deliver competant and timely support.  Quality support begins with warehousing ALL parts to the machine you purchase – in our facilites.  That way if you have an issue with your laser cutter we can not only diagnose the problem we can also ship you the part you need same or next day.  This way you experience minimal down time.

We 100% Guarantee With Our 30-Day Guarantee Return Policy

What about Boss’ return policy?  You have thirty (30) full days to test drive your BOSS LASER machine for yourself.  Engrave, cut, and prove it for yourself!  We Guarantee a quality machine backed by quality support!  See details here:  BOSS Guarantee & Warantee Policy

INLINE BEAM COMBINER

Inline with the path of laser beam a red dot is accurately illuminated on your material start point for improved accuracy and alignment

4 X's MORE SPEED & ACCELERATION

BOSS' New HYBRID SERVO DRIVE™ gives you high performance
Hybrid Servo Motors and drivers with closed-loop feedback, high positioning accuracy and significant speed and acceleration improvement over stepper motors

ALL-IN-ONE LASER HEAD

Improved auto focus laser head offers superior precision and stability vs traditional side mounted pens

NEW! FOCAL LENS

Made-In-USA ZnSe focal lenses for 14% impoved laser beam transmission vs imported optics

AIR ASSIST

Provides critical air flow during laser processing preventing material deformation.
Also, Keeps dust and debris away from laser head preventing focal lens contamination.

MULTI-PLATFORM

Flexible Knife blade & honey comb platforms included for mitigating any laser flashback while cutting material

UPGRADED GANTRY RAILS

High strength linear extrusion rails (X/Y) for handling additional Hybrid Servo motor torque.

Materials

LS-1420 Processing Capabilities Include:

Non metals

Metals

Metals

Non metals

Metals

Metals

Non metals

Metals

Metals

*Laser-able metal blanks have a coating or layer that the laser removes, revealing the design. This machine can process items like brass nameplates and powder-coated stainless steel tumblers.

**Metals can be marked using LaserBond Marking Spray or other pre-treatment.

Specs

Cutting area

  • 19.75" X 13.75"

Laser power

  • CO2 Glass 50W optional 70W (cut up to 3/8" wood / acrylic)

Material capability

  • Organics / non-metal - can mark treated metals

Software Interface

  • LightBurn (Optional)
  • RD Works (Std)

Machine Dimensions

  • 61.5” x 36.6” x 45.3" (70W tube extension plus stand)

Motor type

  • Hybrid Servo Motors - up to 1,500mm

Z-table

  • Push button lower or raise 7.5"

Material platform

  • Includes both Honeycomb & Knife Blade platforms

Venting Attachments

  • Air Exhaust fan w/ extended venting pipe

Platform Capacity

  • Up to 30 lbs. lifting 35 lbs. static

Power Supply

  • Standard AC 110V (220V upon request)

OS Compatibility

  • Windows, Mac OS, or Linux (32 or 64-bit)

Laser / PC Connectivity

  • USB and WiFi networking

Machine Stand

  • STEEL STAND W/ CASTERS FOR MOBILITY: 14" HEIGHT (OPTIONAL ACCESSORY)

Job Memory Capacity

  • 128mb via. USB flash drive

Warranty

  • 2-Years Parts / 1-Year for laser tube

Class

  • Class 4 laser

Net Weight

  • 415 lbs - machine only

Crate Dimensions / Gross Weight

  • 68” L X 42” W X 51” H, 650 lbs

Dimensions

Download spec sheet Have A Question?

WARRANTY



30 DAY-MONEY BACK GUARANTEE


Any feelings of skepticism you might have about investing in a new laser machine is completely normal! This is why BOSS LASER makes every effort to absorb as much risk as possible so you’re free to make a good decision. We want to make it easy for you to prove that our laser systems are quality machines backed by quality support.

We want you as our customer to be 100% satisfied. BOSS LASER guarantees you a 30-Day Return window (beginning the date of receipt) to evaluate your purchase. Click here for details.



2 YEAR LIMITED WARRANTY


BOSS LASER warrants its products and parts against defects in materials or workmanship for two (2) years from the original date of receipt. Click here for details.
